Project an object that is at a different station
1 In the bottom viewport, pan until you can see sample lines SL-3 and SL-8.
2 Click Home tab
drop-down
3 In the bottom viewport, select the blocks that represents trees at SL-3 and
SL-8.
4 Press Enter.
5 In the top viewport, click section view 13+00.
6 In the Project Objects To Section View dialog box, click
each column to specify the following parameters:
Style: Projection Without Exaggeration
Elevation Options: Surface
Label Style: Offset Elevation
7 Click OK.
The tree is displayed on the section view. Two things are evident:
Only one of the blocks was projected onto the section view. Objects
in a site can be projected to a section view only if the object falls
within the perpendicular swath width at the specified sample line.
The block at SL-3 was not projected onto the section view because
the block offset value is greater than the perpendicular swath that is
encompassed by SL-13. The black, dashed lines in the following image
illustrate the sample line extents at SL-13.
584 | Chapter 15 Sections Tutorials
Profile & Section Views panel
Project Objects To Section View
Corridor - (1) Surface - (1)
Section Views
.
<Set All> in
