6 Click
7 On the Watershed Display dialog box, click
and Boundary Segment to turn off the display of these watershed types.
8 Click OK twice.
The watersheds are displayed on the surface in the drawing.
9 In Toolspace, on the Prospector tab, expand the Surfaces
collection. Click the Watersheds collection.
The Prospector list view displays a tabular list of the surface watersheds
with their IDs, description, type, and the ID of the watershed that they
drain into.
10 Optionally, pan or zoom to an individual watershed. Right-click the
watershed item in the list view and click Pan To or Zoom To.
To continue this tutorial, go to
99).

Exercise 3: Creating a Watershed Legend

In this exercise, you will add a watershed legend table to the drawing.
For more information, see the AutoCAD Civil 3D Help topic Adding Surface
Legend Tables.
This exercise continues from
(page 98).
Create a watershed legend table
NOTE This exercise uses Surface-5A.dwg with the modifications you made in the
previous exercise, or you can open Surface-5B.dwg from the
folder (page 819).
1 In Toolspace, on the Settings tab, expand the Surface
Styles
2 Right-click the Standard style. Click Edit.
3 In the Table Style dialog box, on the Data Properties tab, clear the Sort
Data check box.
.
Exercise 3: Creating a Watershed Legend
Exercise 2: Generating a Watershed Analysis
Watershed collection.
Exercise 3: Creating a Watershed Legend | 99
next to Boundary Point
XGND
(page
tutorial drawings
Table
