Autodesk CIVIL3D - CIVILDESIGNCOMP 2007 SLM CD Tutorials Manual page 67

3 Click Point Cloud tab
Surface.
4 In the Add Points to Surface wizard, on the Surface Options page, specify
the following parameters:
Name: Point Cloud Surface
Surface Style: Contours 0.5' and 2.5' with Points
NOTE You may also add the point cloud points to an existing surface in the
current drawing.
5 Click Next.
6 On the Region Options page, under Specify a Region Option, select Object.
7 Click Define Region in Drawing.
8 In the drawing, select the polygon.
9 Click Next.
10 On the Summary page, expand the collections in the Property table, and
ensure that the properties match what you specified earlier in this exercise.
If the property values do not match, use the links on the left side of the
dialog box to return to the previous pages.
11 Click Finish.
The gray surface contours and cyan surface points are displayed in the
drawing, and a surface object is displayed in Toolspace on the Prospector
tab.
Exercise 3: Adding Point Cloud Data to a Surface | 55
Point Cloud Tools panel Add Points to
