Specify a plot style and a layout template
On the Section Placement page, you specify how the section views are displayed
and arranged in the sheets. Select a template, viewport scale, and the group
plot style.
1 Under Placement Options, select Production.
NOTE The Draft option creates section views in the current drawing only.
You cannot generate sheets from Draft section views.
2 Under Template for Cross Section Sheet, click
3 In the Select Layout As Sheet Template dialog box, click
4 In the
Section.dwt is selected. Click Open.
5 In the Select Layout As Sheet Template dialog box, under Select A Layout
To Create New Sheets, select ARCH D Section 40 Scale.
6 Click OK.
7 On the Create Multiple Section Views wizard, under Group Plot Style,
select Basic.
8 Click Next.
Specify the section view offsets
1 On the Offset Range page, under Offset Range, select Automatic.
Notice that the Left and Right values are 150. This is the sample line
swath width value that you specified in
(page 570).
2 Click Next.
Specify the height of the section views
1 On the Elevation Range page, specify the following parameters:
User Specified: Selected
Height: 100.000'
Section Views Height Option: Follow A Section
574 | Chapter 15 Sections Tutorials
Local Template folder (page 819), make sure that Civil 3D (Imperial)
.
.
Exercise 1: Creating Sample Lines
