Examine the Annotate tab
NOTE This exercise uses Labels-1a.dwg with the modifications you made in the
previous exercise.
1 Click the Annotate tab.
This tab contains both AutoCAD Civil 3D and standard AutoCAD
annotation tools.
2 Click Labels and Tables panel
Notice that the menu consists of label and table commands for the
AutoCAD Civil 3D features. You can access the label or table commands
for each feature directly from this menu.
3 Press Esc.
4 Click Add Labels.
In the Add Labels dialog box, you can select the feature, label type, and
label style. This dialog box enables you to easily switch these settings as
needed while annotating your drawing. You will use this dialog box
throughout the labels tutorials.
5 Click Close.
Examine the object tabs
1 Click Modify tab
2 Click Surface tab
Notice that the menu consists of label and table commands for surfaces
only. Each object tab contains an object-specific list of label and table
commands.
To continue to the next tutorial, go to
(page 744).

Tutorial: Adding and Editing Labels

This tutorial demonstrates how to add labels to AutoCAD Civil 3D objects,
and then edit the labels to suit your requirements.
744 | Chapter 19 Labels and Tables Tutorials
Add Labels drop-down.
Ground Data panel Surface.
Labels and Tables panel
Tutorial: Adding and Editing Labels
Add Labels drop-down.
