3 In the bottom viewport, select the multi-view block that represents a tree
at station 13+00.
4 Press Enter.
5 In the top viewport, click section view 13+00.
6 In the Project Objects To Section View dialog box, click
each column to specify the following parameters:
Style: Projection Without Exaggeration
Elevation Options: Surface
Label Style: Offset and Elevation
7 Click OK.
The block is displayed on the section view.
580 | Chapter 15 Sections Tutorials
EG
<Set All> in
