16 On the Multiple Plot Options page, set Maximum in a Row to 4.
17 Click Create Profile Views.
18 When prompted, pan and zoom to a clear area in the drawing window,
then click to create the profile views.
19 In Toolspace, on the Prospector tab, expand the Alignments, Oak Road,
and Profile Views collections.
Notice that a separate profile view was created for each 500.00' segment.
To continue this tutorial, go to
326).

Exercise 6: Creating Stacked Profile Views

In this exercise, you will create a series of three profile views that contain a
centerline and left and right offset profiles.
Stacked profile views are a collection of related profiles that are drawn in
separate, vertically arranged profile views. When each profile is displayed on
its own profile view grid, more space is available to annotate each profile.
326 | Chapter 9 Profiles Tutorials
Exercise 6: Creating Stacked Profile Views (page
