This exercise uses the drawing Grading-3A.dwg, which contains two grading
groups that use the same grading criteria.
Edit the grading criteria
1 Open Grading-3A.dwg, which is located in the
819).
2 Click Modify tab
3 Click Grading tab
4 Click inside the grading that projects from feature line AB.
5 In the Grading Editor Panorama, change the distance value to 5.0000.
Notice that grading AB updates to reflect the change. Now, you will make
a similar change that will affect all grading groups using the Distance @
-6% grading criteria.
6 In Toolspace, on the Settings tab, expand Grading
Sets
7 Right-click Distance @ -6%. Click Edit.
8 In the Grading Criteria dialog box, click the Criteria tab. Change the
Distance parameter to 20 and click
which will apply it to all grading objects that currently use the Distance
@ -6% grading criteria. Leaving the value unlocked applies the value to
only grading objects that are created in the future.
9 Click OK.
The AB and BC grading objects are both updated in the drawing to
account for the new criteria value.
To continue to the next tutorial, go to
Footprint
Tutorial: Grading from a Complex Building
Footprint
This tutorial demonstrates how to grade around a building footprint that has
relatively complicated geometry and variations in elevation.
404 | Chapter 11 Grading Tutorials
Design panel
Modify panel
Ditch Criteria Set.
(page 404).
tutorial drawings folder
Grading.
Grading Editor .
Grading Criteria
. This locks the attribute value,
Grading from a Complex Building
(page
