Label the parcel segments
NOTE This exercise uses Labels-4a.dwg with the modifications you made in the
previous exercise.
1 Click Annotate tab
menu Parcel Add Parcel Labels
2 In the Add Labels dialog box, specify the following parameters:
Label Type: Multiple Segment
Line Label Style: Parcel Line Label Style
Curve Label Style: Parcel Curve Label Style
Radius
3 Click Table Tag Numbering.
4 In the Table Tag Numbering dialog box, examine the settings that are
available.
The settings specify the starting number and increment for line, curve,
and spiral tags. Notice that there are separate starting number and
increment properties for both Table Tag Creation and Table Tag
Renumbering. For this exercise, accept the default value of 1 for all
properties. When you convert the labels to table tags, they will all use a
starting number and an increment of 1. You will use the Table Tag
Renumbering properties later.
5 In the Table Tag Numbering dialog box, click Cancel.
6 In the Add Labels dialog box, click Add.
7 Click the parcel area labels in the following order: 39, 40, 41, 37, 38. Press
Enter to accept the default Clockwise label direction.
As you click, labels are placed on each parcel segment. If you wish, zoom
in to inspect the labels before you convert them to tags.
Labels & Tables panel
.
Exercise 2: Converting Labels to Tags | 771
Add Labels
Bearing Over Distance
Delta Over Length And
