2 Right-click Size Parameters
at the top of the Edit Part Sizes dialog box. The New Parameter dialog
box is displayed.
3 Click Frame Height, and then click OK. The Frame Height (SFH) parameter
is added.
4 Scroll to the right until you see the SFH column. Click Constant in the
SFH column and change it to List. Click the drop-down arrow button
next to Parameter Configuration, and select Values. The values for each
parameter are shown.
5 Click the value cell in the SFH column, and then click the Edit button.
Add the values 8,12, and 16 to the list and then click OK. Set the value
of SFH to 8. This parameter will now be available as three sizes in
AutoCAD Civil 3D.
6 Click OK. Click Save Part Family. This updates the Model Parameters to
include the Size Parameters.
7 Right-click Size Parameters and then click Edit Values. Set the following
values:
SBSL: 120
SBSW: 60
SFL: 108
SFW: 48
SBSH: 48
Click the Update Model button in the Edit Part Sizes dialog box toolbar.
Click OK. This updates the model parameter values to match the size
parameters.
8 Right-click Model Parameters and then click Edit. Set the value of LenB1
to SFH. Click Close. LenB1 is the dimension that represents the depth of
the outer frame extrusion.
Edit Configuration. Click the New button
Exercise 4: Finalizing the Part | 729
