For more information, see the AutoCAD Civil 3D Help topic Using Mass Haul
Diagrams.
Create a mass haul diagram
1 Open Mass Haul-1.dwg, which is located in the
(page 819).
2 Click Analyze tab
3 In the Create Mass Haul Diagram wizard, on the General page, specify
the following parameters:
Mass Haul View Name: Mass Haul Balancing
Mass Haul View Style: Free Haul and Overhaul
4 Click Next.
5 On the Mass Haul Display Options page, examine the settings in the
Material area. The selection in the Material List is saved with the selected
sample line group. To learn how to create a material list, see the
a Material List (page 591) exercise. Examine the options that are available
in the Choose A Material To Display As Mass Haul Line list, but accept
the default Total Volume option. In the Mass Haul Line area, specify the
following settings:
Mass Haul Line Name: Mass Haul Line Total Volume
Mass Haul Line Style: Free Haul and Overhaul- Grade Point
6 Click Next.
7 On the Balancing Options page, under Free Haul Options, select the Free
Haul Distance check box. Enter 300.0000' as the free haul distance.
This value specifies that the distance that the earthmover hauls material
at the standard rate. Material moved beyond this distance is considered
overhaul, and typically is charged at a higher rate.
8 Click Create Diagram.
9 In the drawing, snap to the center of the red circle that is above the profile
view to place the mass haul diagram.
The mass haul diagram is displayed, and contains three mass haul regions.
As shown in the following image, mass haul regions identify station
ranges where material is either cut or fill. When the mass haul line is
Volumes And Materials panel
Exercise 1: Creating a Mass Haul Diagram | 597
tutorial drawings folder
Mass Haul.
Creating
