To create project points, you first create a drawing that contains the points.
When you are ready to share the points with others, you use the Add To Project
command to add the points to the project point database. The project points
can then be accessed by others.
After you create project points with the Add To Project command, a local copy
of the points remains in the drawing. The icons displayed in the points list
view indicate the state of a point with respect to the project.
For more information, see the AutoCAD Civil 3D Help topic Adding Points to
a Project.
In this exercise, you will add points to the project from the drawing
Project-XGND.dwg, which has already been added to the project.
This exercise continues from the
Object Data
Add points to the project
1 In Toolspace, on the Prospector tab, expand Projects collection
Vault Project
Right-click drawing Project-XGND.dwg, and click Open (Read-Only).
2 On the Prospector tab, in the Open Drawings collection, under
Project-XGND, click Points to display the points list view.
3 In the points list view, select all the points by clicking the first row and
then pressing Ctrl+A.
4 Right-click, and then click Add to Project.
This operation may take a few moments.
NOTE You can also add all points in a drawing to a project by expanding
the Point Groups collections, right-clicking the _All Points point group, and
clicking Add Points To Project.
5 In the Add To Project dialog box, click OK.
NOTE If you are prompted to check out the drawing, click No.
6 In the points lists view, the open lock
each point. The icon indicates that it is a project point that is available
to be checked out.
208 | Chapter 7 Project Management Tutorials
Creating, Referencing, and Modifying Project
(page 200) tutorial.
Drawings
Source Drawings
Surfaces folder.
icon is now displayed next to
Tutorial
