Radius: 75.00
Arc Length: 80.800
10 Click
11 Expand the Side 4 collection. Specify the following parameters:
Side Type: Line
Angle: N90 00 00E
Distance: 99.990
12 Click
13 Expand the Side 5 collection. Specify the following parameters:
Side Type: Line
Angle: S0 00 00E
Distance: 100
14 Click
15 Expand the Side 6 collection. Specify the following parameters:
Side Type: Line
Angle: N89 59 54W
Distance: 149.990
The direction arrow meets the point of beginning.
178 | Chapter 6 Survey Tutorials
New Side.
New Side.
New Side.
