For more information, see the AutoCAD Civil 3D Help topic Creating and
Editing Section Views.
This exercise continues from
Modify the group plot style
1 Open Sections-Views-Create.dwg, which is located in the
folder (page 819).
2 In Toolspace, on the Settings tab, expand the Section View
Plot Styles collection. Select the Basic style. Right-click. Click Edit.
3 In the Group Plot Style dialog box, click the Display tab.
4 Under Component Display, in the Print Area row, change the Color to
Red.
These colors make it easy to identify the extents of the sheet, as well as
the portion of the sheet that contains the section views. You will observe
these components when you create the section views later in this exercise.
5 Click OK.
Specify basic section view parameters
1 Click Home tab
drop-down Create Multiple Views
2 In the Create Multiple Section Views wizard, on the General page, specify
the following parameters:
Select Alignment: Centerline (1)
Sample Line Group Name: SLG-1
Station Range: User Specified
Start: 0+00.00
End: 10+00.00
Section View Style: Road Section
3 Click Next.
Exercise 1: Creating Sample Lines
Profile & Section Views panel
.
Exercise 2: Creating Section Views | 573
(page 570).
tutorial drawings
Group
Section Views
