NOTE The contents of the Favorites category are saved with the drawing.
To save time during this tutorial, the pay items you will use are saved as
Favorites in subsequent drawings.
To continue this tutorial, go to
AutoCAD Objects
Exercise 2: Assigning Pay Item Codes to AutoCAD
Objects
In this exercise, you will assign pay item codes to a variety of AutoCAD objects,
including lines, blocks, and closed polyline areas.
You will use the AutoCAD Quick Select and Select Similar commands to select
similar objects. You can use these commands to assign a pay item code to
many objects at the same time.
For more information, see the AutoCAD Civil 3D Help topic Tagging Objects
with Pay Items.
This exercise continues from
List (page 604).
Assign a pay item code to linear objects
1 Open Quantities-2.dwg, which is located in the
(page 819).
This drawing contains a commercial site, which consists of a building
footprint, a parking lot, and access roads.
2 On the command line, enter QSELECT.
3 Click OK to acknowledge that objects were not selected.
4 In the Quick Select dialog box, specify the following parameters:
Apply To: Entire Drawing
Object Type: Line
Properties: Layer
Operator: = Equals
Value: PKNG-STRP-AISLES
606 | Chapter 16 Material Calculation Tutorials
Exercise 2: Assigning Pay Item Codes to
(page 606).
Exercise 1: Loading and Navigating a Pay Item
tutorial drawings folder
