3 In the Create Profile View wizard, on the General page, specify the
following parameters:
Select Alignment: North-South Road
Show Offset Profiles By Vertically Stacking Profile Views: Selected
The graphic at the bottom of the page changes color to indicate that
the option is active.
NOTE The Profile View Style setting on this page is not used. You will assign
separate styles for each profile view in the stack.
4 On the left side of the Create Profile View wizard, click Stacked Profile.
5 On the Stacked Profile page, specify the following parameters:
Number Of Stacked Views: 3
Gap Between Views: 0
NOTE The Gap Between Views value is measured in drawing units. A
positive value adds space between the profile view grids. A negative value
causes the profile view grids to overlap.
Top View Style: Stacked - Top
Middle View Style: Stacked - Middle
Bottom View Style: Stacked - Bottom
6 Click Next.
7 On the Profile Display Options page, in the Select Stacked View To Specify
Options For list, select Middle View.
NOTE The number of views that is visible in this list depends on the value
you specified for Number Of Stacked Views in Step 5.
8 In the Specify Profile Display Options table, select the Draw check box
for the following profiles:
EG Centerline
Centerline
9 In the Select Stacked View To Specify Options For list, select Top View.
328 | Chapter 9 Profiles Tutorials
