Before starting this exercise, ensure that you are logged in to the database as
pred, or the same user who checked out the drawing Project-XGND.dwg.
Check in a project object
1 On the Prospector tab, expand the Open Drawings collection.
2 Right-click Project-XGND, and click Check In.
3 In the first Check In Drawing dialog box, verify that Project-XGND.dwg
is selected.
4 Click Finish.
The drawing is checked in and closed.
5 Expand the Projects
Drawings collection. Select the Surfaces folder to display the list view.
In the list view, note that the Version for file Project-XGND.dwg has
changed from 1 to 2. Version 2 is the drawing containing the project
surface with the most recent modifications.
To continue this tutorial, go to
206).

Exercise 5: Updating a Project Object

When the drawing that contains a project object is checked in to the database,
the changes are immediately available to other drawings that reference the
object.
In this exercise you will open the drawing Project-1.dwg that references the
surface XGND, which was modified in the previous exercise.
For more information, see the AutoCAD Civil 3D Help topic Getting the Latest
Version of Project Objects.
This exercise continues from
205).
