All the light posts along the proposed road corridor are selected.
When you insert a multi-view block into a drawing, it is created as a
standard AutoCAD block. Before it can be projected onto a profile view,
a multi-view block must be exploded from its original AutoCAD block
form.
3 Click Home tab
drop-down
4 In the right viewport, click the profile view grid.
5 In the Project Objects to Profile View dialog box, click
each column to specify the following parameters:
Style: Projection Without Exaggeration
Elevation Options: Surface
Label Style: Object Name Station And Elevation
6 Click OK.
The light poles are displayed on the profile view.
316 | Chapter 9 Profiles Tutorials
Profile & Section Views panel
Project Objects To Profile View.
First Street Surface
Profile View
<Set All> in
