Individual label objects that are part of a group, such as a single alignment
station label.
Individually labeled objects in the Prospector list view, including parcels,
points, and pipe network objects.
See Exercise 1: Creating a Parcel Area Table
changing parcel area label styles using the Prospector list view.
For more information, see the AutoCAD Civil 3D Help topic Modifying Labels
in a Drawing.
This exercise continues from
(page 789).
Change the label style of a single label object
NOTE This exercise uses Labels-5b.dwg with the modifications you made in the
previous exercise, or you can open Labels-5c.dwg from the
(page 819).
1 Pan and zoom to the area at the end of the West Street cul-de-sac.
2 Click the red curve label between stations 0+200 and 0+220 on West
Street.
Grips appear on the curve label, but no other labels are selected. This
label is a single label object that is not part of a group of labels.
3 Right-click the label. Click Properties.
4 On the Properties palette, in the Curve Label Style list, notice that you
can select a General Curve Label Style. General styles can be applied to
line and curve labels that annotate alignment, profile, or parcel segments.
Select General Curve Label Style
The individual curve label style changes, but the remaining curve labels
on the cul-de-sac are not affected.
5 Press Esc to deselect the label.
794 | Chapter 19 Labels and Tables Tutorials
(page 768) for information about
Exercise 4: Changing the Dragged State of a Label
Radius Only.
tutorial drawings folder
