6 In the Profile Label Set dialog box, on the Labels tab, specify the following
parameters:
Type: Horizontal Geometry Points
Profile Horizontal Geometry Point: Station & Type
7 Click Add.
8 In the Geometry Points dialog box, examine the geometry points that
can be labeled. You can specify any combination of points that you want
to label. Click OK.
NOTE For more details about geometry point labels, see the
in Groups tutorial exercise
9 In the Profile Label Set dialog box, click OK.
10 Click the Design Criteria tab.
The options on this tab are used only if you want to ensure that the
profile design meets specified design criteria. You will not apply design
criteria to the profile in this exercise. You will learn how to use the design
criteria feature in the
tutorial
11 Click OK to accept the settings.
Draw the layout profile
1 In the Profile Layout Tools toolbar, click the arrow on the right side of
and click Curve Settings.
2 On the Vertical Curve Settings dialog box, specify the following
parameters:
Curve Type: Parabolic
Crest Curve Length: 100
Sag Curve Length: 100
Notice that you can select one of three curve types and specify parameters
for each type.
3 Click OK.
290 | Chapter 9 Profiles Tutorials
(page 745).
Designing a Profile that Refers to Local Standards
(page 297).
Adding Labels
