Create a new survey database
1 Open Survey-4B.dwg, which is located in the
819).
2 In Toolspace, on the Survey tab, right-click Survey Databases. Click New
Local Survey Database.
3 In the New Local Survey Database dialog box, for the name, enter Survey
3. Click OK.
4 In Toolspace, on the Survey tab, right-click the database Survey 3. Click
Edit Survey Database Settings.
5 In the Survey Database Settings dialog box, under Measurement Type
Defaults, specify the following parameters:
Angle Type: Angle
Distance Type: Horizontal
Vertical Type: None
Target Type: None
6 Click OK.
Create a survey network
1 In Toolspace, on the Survey tab, expand the Survey 3 database. Right-click
the Networks collection. Click New.
2 In the Network dialog box, for Name, enter Survey Network 3.
3 Click OK.
Set up a traverse and define control points
1 In Toolspace, on the Survey tab, expand the Survey Databases
3 Networks Survey Network 3. Right-click the Traverses collection.
Click New.
2 In the New Traverse dialog box, for Name, enter Traverse 3. Click OK.
3 On the Survey tab, select the Traverses collection. In the list view,
right-click Traverse 3. Click Edit Traverse.
4 In the Specify Initial Setup dialog box, specify the following parameters:
Initial Station: 1
Exercise 2: Creating Survey Data Using the Traverse Editor | 161
tutorial drawings folder (page
Survey
