2 Click Analyze tab
3 In the QTO Manager vista, click
4 In the Quantity Takeoff Command Settings dialog box, under Compute
Takeoff Options, specify the following parameters:
Length Computation Type: 3D
Pipe Length Type: To Inside Edges
These parameters specify that the pipe lengths will be reported, using the
end-to-end distance, from the inside edge of each structure.
5 Click OK.
Add pay item codes to a pipe network
1 In the drawing, select a pipe network part. Click Pipe Networks
tab Modify panel
2 In the Pipe Network Properties dialog box, on the Layout Settings tab,
under Network Parts List, click
3 In the Network Parts List dialog box, on the Pipes tab, expand the Storm
Sewer Concrete Pipe category.
4 In the 18 inch RCP row, click
5 In the Pay Item List dialog box, expand the
6 In the Favorites category, select Pay Item ID 60201-0600.
7 Click OK.
8 Click the Structures tab.
9 Repeat Steps 4 through 7 to assign pay items to the following structures:
Structure
51 x 6 x 51 inch Concrete Rectangular Headwall
Mat_CONC
Eccentric Structure 48 dia 24 frame 24 cone 5 wall 6 floor
Mat_CONC
Exercise 3: Assigning Pay Item Codes to Pipe Network Parts | 613
QTO panel QTO Manager.
.
Network Properties.
Edit Current Selection.
.
Favorites category.
Pay Item ID
60103-0100
60403-1100 60409-0500
