2 Click Home tab
drop-down
3 In the right viewport, click the profile view grid.
4 In the Project Objects To Profile View dialog box, click
5 In the left viewport, zoom out and select each of the blue 3D polylines
that represent the front of building footprints.
6 Press Enter.
7 In the Project Objects To Profile View dialog box, in the
row, under Style, click
8 In the Select Projection Style dialog box, select Projection Without
Exaggeration.
Leave the Elevation Options setting at
appropriate elevation value is a property of the selected objects.
9 Click OK twice.
318 | Chapter 9 Profiles Tutorials
Profile & Section Views panel
Project Objects To Profile View.
<Set All>.
Profile View
Pick Objects.
3D Polylines
Use Object. In this case, the
