The Berm Volume surface is listed in the collection, with an icon
indicate that it is a TIN volume surface.
View the volume surface statistics
1 On the Prospector tab, right-click the Berm Volume surface. Click Surface
Properties.
2 In the Surface Properties dialog box, click the Statistics tab. Expand the
Volume statistics to see the cut, fill, and net volumes.
Further exploration: If you want to add the data from the Statistics tab
to the drawing, right-click the statistics table and click Copy To Clipboard.
Then close the Surface Properties dialog box, zoom in to a clear space in
the drawing, right-click, and click Clipboard
of the Statistics tab (General, TIN, and Volume) are pasted in. To edit the
text content and format, right-click and click MText Edit. Another useful
option is to paste the statistical data from the clipboard into a separate
spreadsheet.
3 If necessary, click OK to close the Surface Properties dialog box.
To continue this tutorial, go to
Calculation

Exercise 3: Creating a Composite Volume Calculation

In this exercise, you will use the Composite Volume utility to calculate volume
information between two surfaces.
For more information, see the AutoCAD Civil 3D Help topic Calculating
Composite Volumes.
This exercise continues from
109) and presents an alternative method for generating the surface volume
statistics.
Create composite volume information
NOTE This exercise uses Surface-6.dwg with the modifications you made in the
previous exercise.
1 Click Analyze tab
drop-down
110 | Chapter 5 Surfaces Tutorials
Exercise 3: Creating a Composite Volume
(page 110).
Exercise 2: Creating a TIN Volume Surface
Volumes And Materials panel
Volumes .
to
Paste. The entire contents
(page
Volumes
