Click in circle 8 and select EPS to define the left-outside edge of the
paved shoulder.
Click in circle 2.
On the command line, enter C to close the boundary.
Change the name of the boundary to Median.
Change the Use Type to Outside Boundary.
3 Click OK to create the boundaries and close the Corridor Properties dialog
box.
To continue this tutorial, go to

Exercise 3: Visualizing a Corridor

In this exercise, you will visualize the corridor using the rendering and
hatching features in AutoCAD Civil 3D.
Rendering a corridor requires that you assign an AutoCAD render material to
each of the appropriate subassembly links. Rendering produces a realistic
image of the corridor that is useful for on-screen presentations.
Applying hatching to a corridor requires that you apply a material area fill style
to each of the appropriate subassembly links. Hatching produces a less realistic
image of the surface than rendering, but hatching prints easily through
AutoCAD.
For more information, see the AutoCAD Civil 3D Help topic Rendering Corridor
Models.
This exercise continues from
(page 486).
Apply 3D render materials to a corridor
1 Open Corridor-5c.dwg, which is available in the
(page 819).
2 In the drawing, select the corridor.
TIP If you have difficulty selecting the corridor in the drawing, go to the
Toolspace Prospector tab. Expand the Corridors collection. Right-click the
corridor name and click Select.
490 | Chapter 13 Corridors Tutorials
Exercise 3: Visualizing a Corridor
Exercise 2: Creating Corridor Surface Boundaries
(page 490).
