11 Right-click Vertical Axis
horizontal line, and then the arc. Repeat for the arc and the vertical
segment of the drop pipe. The drop pipe bend arc is constrained to be
tangent with the horizontal and vertical segments of the pipe.
12 Right-click Vertical Axis
and then top points at the ends of the top segment of the centerline.
Click a point to set the location of the dimension. A dimension named
LenA1 is created for the line segment representing the frame height.
682 | Chapter 18 Part Builder Tutorials
Add Constraints
Tangent. Select the lower
Add Dimension
Distance. Click the bottom
