Specify the slip lane parameters
1 In the Draw Slip Lane dialog box, under Slip Lane Parameters, specify the
following parameters:
Segmentation Line Length: 1
Length of Deceleration Lane: 20
Length of Acceleration Lane: 10
Lane Width: 4
Radius: 50
Taper Length: 20
2 Under Draw Pavement Markings, specify the following parameters:
Outer Edge: Selected; Continuous
Decelerating Transition Line: Cleared
Accelerating Transition Line: Cleared
552 | Chapter 14 Intersection and Roundabout Tutorials
