Exercise 3: Performing a Mapcheck Analysis by Manually
Entering Data
In this exercise, you will manually enter survey data to perform a mapcheck
analysis.
This method of performing a mapcheck analysis is useful when you must
check survey data that does not exist as labels in the drawing. For example,
you can use this method to enter survey data from a paper drawing.
For more information, see the AutoCAD Civil 3D Help topic Manually Entering
Mapcheck Data.
This exercise continues from
Parcel Labels
Set up the mapcheck analysis dialog box
NOTE This exercise uses Survey-5B.dwg with the modifications you made in the
previous exercise.
The parcel segments on the right side of the site are not labeled. Because the
data is not available in parcel labels, you must enter the mapcheck information
manually.
1 Click Analyze tab
.
2 If a message that states the command line mode cannot be used while a
command is active is displayed, click OK.
3 In the Mapcheck Analysis dialog box, make sure that the
Command Line Interface option is toggled off.
4 Click
The input view provides an interface in which you can add data to the
mapcheck analysis.
Enter parcel data
1 Click
176 | Chapter 6 Survey Tutorials
Exercise 2: Performing a Mapcheck Analysis with
(page 173).
Ground Data panel
Input View.
New Mapcheck.
Survey drop-down Mapcheck
Use
