11 In the Browse For Folder dialog box, navigate to the
folder (page 819). Click Open.
12 Click Next.
NOTE If the view frames do not include any profile views, then the Profile
Views page in the Create Sheets wizard is skipped. The Data References page
is displayed next.
13 On the Profile Views page, under Other Profile View Options, select
Choose Settings.
NOTE You specified the Profile View Settings during
View Frames (page 807).
14 Click Profile View Wizard.
15 In the Create Multiple Profile Views wizard, use the links along the left
side or the Back and Next buttons to examine the available settings. Many
of the settings are not available because they are already defined by the
currently selected view frame group.
For more information, see the
tutorial exercise.
16 Click Finish.
17 In the Create Sheets wizard, under Align Views, select Align Profile And
Plan View At Start.
This option aligns the alignment starting station in plan view with the
profile starting station in profile view. The profile view shifts to the right
to accommodate the exact alignment starting station.
18 Click Next.
19 On the Data References page, you can select or omit the objects for which
you want references included in your sheets. Notice that the Maple Road
alignment and profile are selected by default.
20 Select the check box next to Pipe Networks.
Create sheets
1 Click Create Sheets to close the wizard and create the sheets. When you
are prompted to save the current drawing, click OK.
Creating Multiple Profile Views
Exercise 1: Creating Plan and Profile Sheets | 813
