Modify the surface: Use the DeleteSurfacePoint command to delete surface
points that are located exactly on the polylines.
Modify the polylines: Add a vertex to the polylines at each location where
it crosses a surface contour.
To continue this tutorial, go to
Surface (page 70).

Exercise 4: Adding an Outer Boundary to a Surface

In this exercise, you will insert a polyline from an external DWG file and
create an outer surface boundary from the polyline.
For more information, see the AutoCAD Civil 3D Help topic Boundaries.
This exercise continues from
65).
70 | Chapter 5 Surfaces Tutorials
Exercise 4: Adding an Outer Boundary to a
Exercise 3: Adding Breaklines to a Surface (page
