Tutorial: Working with Offset Alignments

This tutorial demonstrates how to create and modify offset alignments that
are dynamically linked to a centerline alignment.
The process of creating offset alignments is similar to that of the standard
AutoCAD OFFSET command. However, an offset alignment is dynamically
linked to either the geometry or stationing of the centerline alignment from
which it was created. As the parent alignment geometry changes, the offset
alignment updates.
