Material Calculation
Tutorials
These tutorials will get you started working with the AutoCAD Civil 3D tools for calculating
and reporting material quantities and volumes.
In the following tutorials, you will learn how to use the material calculation tools:
Corridor Earthwork Volume tools compare an existing and proposed surface at specified
alignment stations. An earthwork volume report lists the cumulative cut and fill volumes,
as well as the incremental volume at each specified station.
Mass Haul Diagrams display cut and fill volumes along an alignment. Mass haul diagrams
illustrate the distance over which cut and fill volumes balance, the volume of material to
be moved, and the locations of borrow pits and dump sites.
Pay Item Quantities extract and report the cost of a project based on the quantity of pay
items that are assigned to AutoCAD or AutoCAD Civil 3D objects in the project.
NOTE All drawings used in these tutorials are available in the
. If you want to save your work from these tutorials, save the drawings to the
819)
Tutorial Data folder (page 819)
For more information, see the AutoCAD Civil 3D Help topic Material and Quantity Analysis.
Tutorial: Calculating Earthwork Volumes from
Corridor Models
This tutorial demonstrates how to calculate cut and fill earthwork quantities
between two surfaces.
so that you do not overwrite the original drawings.
16
tutorial drawings folder (page
My Civil
589
