4 Click Add.
5 In the drawing window, click Pipe - (1), which is between stations 7+00
and 8+00 of the layout profile displayed in the profile view.
The pipe is labeled with its description. In the following steps, you will
create a label style that displays the elevation of the start invert of the
pipe.
Create a pipe label style
1 In the Add Labels dialog box, next to the Pipe Label Style list, click the
arrow next to . Click
2 In the Label Style Composer dialog box, on the Information tab, for
Name, enter Start Invert Elevation.
3 On the Layout tab, click the Contents value under Text. Click
4 In the Text Component Editor dialog box, on the Properties tab, in the
Properties list, select Start Invert Elevation.
5 Click .
6 In the text editor window, click the <[Description(CP)]> property field.
Press Delete.
7 Your label content should look like this:
8 Click OK twice.
9 In the Add Labels dialog box, specify the following parameters:
Label Type: Single Part Profile
Pipe Label Style: Start Invert Elevation
10 Click Add.
11 In the profile view, click Pipe - (2), which is between stations 8+00 and
9+50 of the layout profile.
12 Press Esc to end the add label command.
13 Click the label text to select the label.
Exercise 2: Adding Labels to Pipe Network Parts | 647
Copy Current Selection.
.
