Add a lane subassembly
1 If the Tool Palette containing the subassemblies is not visible, click Home
tab Palettes panel
2 In the tool palette, right-click the Tool Palettes control bar. Click Civil
Metric Subassemblies.
3 Click the Lanes tab.
4 Click LaneOutsideSuper.
5 In the Properties palette, under ADVANCED, specify the following
parameters:
Side: Right
Width: 3.5
6 In the drawing, click the marker point on the assembly baseline.
The right lane subassembly is now attached to the assembly baseline.
Tool Palettes .
Exercise 1: Creating an Assembly | 423
