Tutorial: Generating Sheets for Plotting

This tutorial demonstrates how to generate plot-ready sheets that display
either plan and profile or cross sections.
For more information, see the AutoCAD Civil 3D Help topics Plan/Profile Sheet
Production and Section Sheet Production.

Exercise 1: Creating Plan and Profile Sheets

In this exercise, you will create plan and profile sheets from the view frames
you created in an earlier exercise.
After you have used the Create View Frames wizard to create view frames,
then you can create sheets using the Create Sheets wizard.
The sheets that are created represent the layouts (sheets) that are used for
construction documents (plans).
For more information, see the AutoCAD Civil 3D Help topic Creating Plan/Profile
Sheets.
Specify the sheet creation settings
1 Open Plan Production-Plan Profile Sheets-Create.dwg, which is located in
the tutorial drawings folder
The current drawing must be saved before you create section sheets. To
prevent the tutorial drawing from being overwritten, save it to an alternate
location.
2 Click
3 In the Save Drawing As dialog box, navigate to the
folder
4 Click Output tab
(page 819).
Save As.
(page 819). Click Save.
Plan Production panel
Tutorial: Generating Sheets for Plotting | 811
Generating Sheets for Plotting
My Civil Tutorial Data
Create Sheets
(page
.
