10 In the Specify Profile Display Options table, select the Draw check box
for the following profiles:
EG Left Offset
EOP Left
11 In the Select Stacked View To Specify Options For list, select Bottom View.
12 In the Specify Profile Display Options table, select the Draw check box
for the following profiles:
EG Right Offset
EOP Right
13 Click Next.
14 On the Pipe Network Display page, in the Select Stacked View To Specify
Options For list, select Bottom View.
Most of the pipe network is on the right-hand side of the alignment. You
will specify that the pipe network components will be displayed in the
profile view that displays the right EOP profiles.
15 In the Select Pipe Network Parts To Draw In Profile View area, select the
Select check box.
16 In the Name column, expand the Network - (1) pipe network.
17 Clear the check boxes for the following parts:
W-E Pipe - (1)
W-E Pipe - (2)
W-E Structure - (1)
W-E Structure - (2)
These parts are a branch of the pipe network that follow the West-East
alignment.
18 In the Select Stacked View To Specify Options For list, select Middle View.
19 In the Select Pipe Networks To Draw In Profile View list, select the Select
check box.
20 Clear all check boxes except for the following parts:
W-E Pipe - (1)
