5 Click MedianDepressedShoulderExt.
6 In the Properties palette, under ADVANCED, specify the following
parameters:
Centerline Pivot: Pivot about centerline
Left Median Width: 22.0000
Right Median Width: 22.0000
7 In the drawing, click the marker point on the assembly baseline. A
depressed median and inside shoulders are drawn.
Add a lane subassembly
1 In the drawing, pan to the left edge of the MedianDepressedShoulderExt
subassembly. Zoom in so that each marker point can be seen distinctly.
2 In the tool palette, click the Lanes tab.
3 Click LaneOutsideSuper.
This subassembly inserts a travel lane that follows the outside lane
superelevation slope for the superelevation properties of the alignment.
NOTE For more information about superelevation, see the
Superelevation to an Alignment
4 In the Properties palette, under ADVANCED, specify the following
parameters:
Side: Left
Width: 24.0000
5 In the drawing, click the marker that is at the top left edge of the median
to insert the lane:
Exercise 1: Creating a Divided Highway Assembly | 473
(page 262) tutorial.
Applying
