You will correct the violations in
Alignment Design Criteria Violations
Second, you will create an alignment entity that meets the design criteria
specified in the design criteria file. You will use the minimum default
values that are displayed on the command line to ensure that the entity
meets the specified design criteria.
For more information, see the AutoCAD Civil 3D Help topic Creating an
Alignment Using the Alignment Layout Tools.
Specify design criteria for an alignment
1 Open Align-7A.dwg, which is located in the
819).
The drawing contains a surface marked with several circles, labeled A
through E.
NOTE Ensure that Object Snap (OSNAP) is turned on. For more information,
see Object Snapping
2 Click Home tab
drop-down Alignment Creation Tools
3 In the Create Alignment – Layout dialog box, accept the default values
for Name and Starting Station. Leave the Description field blank for this
exercise.
4 On the General tab, specify the following parameters:
Site: <None>
Alignment Style: Design Style
Alignment Layer: C-ROAD
Alignment Label Set: Major Minor and Geometry Points
5 On the Design Criteria tab, for Starting Design Speed, enter 50 km/h.
This speed will be applied to the starting station of the alignment. You
can add design speeds as needed to other stations. A design speed is
applied to all subsequent stations until either the next station that has
an assigned design speed or the alignment ending station.
6 Select the Use Criteria-Based Design check box.
Exercise 1: Drawing an Alignment that Refers to Design Criteria | 249
Exercise 2: Viewing and Correcting
(page 253).
(page 16).
Create Design panel
tutorial drawings folder
Alignment
.
(page
