3 Click Intersection tab
The offset alignment parameters are displayed in the Intersection Offset
Parameters dialog box.
4 Under Secondary Road, change the Offset Value for both offset alignments
to 4.000.
Notice that as the values change, the intersection updates in the drawing.
Modify the curb return parameters
1 Click Intersection tab
The Intersection Curb Return Parameters dialog box displays the curb
return alignment parameters for the northeast intersection quadrant.
This dialog box enables you to change basic parameters, as well as specific
details of the curb return at each intersection quadrant.
In the drawing, notice that the currently selected curb return is
highlighted.
518 | Chapter 14 Intersection and Roundabout Tutorials
Modify panel Edit Offsets
Modify panel Edit Curb Returns
.
.
