! POINT 2
259.9600
7 Close the Survey Command Window.
To continue this tutorial, go to
150).

Exercise 2: Performing Traverse Analysis

In this exercise, you will reduce some of the survey data using the traverse
analysis Compass Rule adjustment method.
The Compass Rule is a method of corrections. It assumes that the closing errors
are as much due to errors in observed angles as by the errors in measured
distances. The closing errors in latitude and departure are distributed according
to the ratio of the length of the line to the total length of the traverse.
For more information, see the AutoCAD Civil 3D Help topic Traverses.
This exercise continues from
Set up a traverse
NOTE This exercise uses Survey-3.dwg with the modifications you made in the
previous exercise.
1 In Toolspace, on the Survey tab, expand the Survey Databases
1 Networks
Click New.
2 In the New Traverse dialog box, for Name, enter Traverse 1. Click OK.
3 On the Survey tab, in the list view, right-click Traverse 1, and click
Properties.
4 In the Traverse Properties dialog box, specify the following parameters:
Initial Station: 1
Initial Backsight: 1000
Stations: 2,3,4,5,6
Final Foresight: 6000
5 Click OK.
150 | Chapter 6 Survey Tutorials
NORTH: 5087.9995
Exercise 2: Performing Traverse Analysis
Exercise 1: Querying Survey Data
Survey Network 1. Right-click the Traverses collection.
EAST: 5286.8036
(page
(page 148).
Survey
EL:
