9 In the Alignment Label Set dialog box, in the Geometry Points row, in
the Geometry Points To Label column, click
10 In the Geometry Points dialog box, click
Select the Alignment Beginning check box. Click OK.
You can use geometry point label types to label a selection of geometry
points using a combination of styles that you specify. In steps 8 and 9,
you applied a geometry point label style to the alignment starting station.
In the following steps, you will create another instance of the Geometry
Points label type that applies a different style to the alignment ending
station.
TIP To remove a label type from the label set, select the type and click
.
11 In the Alignment Label Set dialog box, on the Labels tab, specify the
following parameters:
Type: Geometry Points
Geometry Point Label Style: Alignment End
12 Click Add.
13 In the Geometry Points dialog box, click
Select the Alignment End check box. Click OK.
14 In the Alignment Label Set dialog box, click OK.
15 In the Create Alignment - From Polyline dialog box, under Conversion
Options, clear the Add Curves Between Tangents check box. Click OK.
16 Zoom in to the area surrounding the new alignment and examine the
labels that were automatically placed along the alignment.
NOTE If the EP: 0+243.63 label is adjacent to the intersecting alignment,
click Alignment tab
alignment. Click OK to acknowledge the warning about alignment properties
that are affected by the command.
When the alignment is created, it is green. The green color is controlled
by the alignment style that you specified in step 3. Notice that the new
748 | Chapter 19 Labels and Tables Tutorials
Modify panel Reverse Direction
.
to clear all check boxes.
to clear all check boxes.
. Click the
