RetainWallVertical - Left: Retaining Wall (Cut 0-10000 -- Cut 5-10000)
for TR-L
LinkOffsetOnSurface: Daylight Offset On Surface (Cut 0-10000 -- Cut
0-5) for TR-L
LinkSlopeToSurface - Left: Daylight Slope To Surface (Cut 0-10000 --
Fill 0-10000) for TR-L
7 Click OK.
To continue this tutorial, go to
Examining the Results
Exercise 4: Rebuilding the Corridor and Examining the
Results
In this exercise, you will reset the corridor targets, rebuild the corridor, and
then examine how the conditional subassembly affects the corridor model.
For more information, see the AutoCAD Civil 3D Help topic Viewing and Editing
Corridor Sections.
This exercise continues from
Properties
Set targets and rebuild the corridor
1 Open Assembly-2c.dwg, which is available in the
(page 819).
The drawing contains the corridor assembly that you designed in the
previous three exercises.
2 In the drawing, click the Corridor - (1) corridor.
3 Click Corridor tab
drop-down
4 In the Corridor Properties dialog box, on the Parameters tab, click Set All
Targets.
5 In the Target Mapping dialog box, in the Object Name column, click
<Click Here To Set All>.
446 | Chapter 12 Corridor Assembly Tutorials
Exercise 4: Rebuilding the Corridor and
(page 446).
Exercise 3: Adjusting Conditional Subassembly
(page 443).
Modify Corridor panel
Corridor Properties
tutorial drawings folder
Corridor Properties
.
