Warning symbols appear next to each value that violates the design
criteria that are specified in the design criteria file.
7 In row 2, hover the cursor over the
column.
Notice that the tooltip displays the design criteria and design checks that
have been violated. Notice that while the two curves violate the minimum
length specified by the design checks, a warning symbol does not appear
in either Length cell. Design checks are custom, mathematical formulas
that return either a true or false value. They do not provide feedback
other than whether the applicable entities meet or violate the conditions
in the design check.
8 On the Profile Layout Tools toolbar, click
The Profile Layout Parameters window is displayed, containing no data.
9 In the Profile Entities vista, click row No. 4, which is the curve entity in
Circle C.
The design data for the curve entity is displayed in a three-column table
in the Profile Layout Parameters window, where data is easy to review
and edit.
Notice that in the Profile Layout Parameters window, in the Design
Criteria panel, a
property that has been violated. In the Layout Parameters panel, the
Value column displays the actual parameters of each sub-entity. The
Constraints column displays the design criteria values that the sub-entities
must meet. A
the value violates the design criteria. As is true in the drawing window
and Profile Entities Vista, the design check that has been violated is
displayed, but individual parameters that violate the check are not marked.
Correct the design criteria violations
1 In the Profile Layout Parameters window, on the Layout Parameters panel,
change the Length Value to 60.000m. Press Enter.
Notice that the warning symbol is cleared from the Design Checks panel,
as well as from row 4 in the Profile Entities vista. The new curve length
value meets the value specified by the design check. Increasing the curve
length also affected the K value, which increased to meet the minimum
value for Headlight Sight Distance.
Exercise 3: Viewing and Correcting Profile Design Criteria Violations | 303
warning symbol in the No.
symbol is displayed next to the design criteria
symbol is displayed next to the K Value row because
Profile Layout Parameters.
