This exercise continues from
Design Criteria Violations
Create an alignment design check
1 Open Align-7C.dwg, which is located in the
819).
2 In Toolspace, on the Settings tab, expand the Alignment
Checks collection.
Notice that five collections are available. The Design Check Sets collection
contains combinations of design checks. A design check must be added
to a design check set before it can be applied to an alignment.
The other four collections contain the design checks for each type of
alignment entity. Each entity type has specific properties that can be
checked. When you create a design check set, you specify the type of
entity you want to check, and then the specific design check you want
to apply to that entity. You can apply multiple design checks to each
entity type.
NOTE The Tangent Intersection collection contains design checks for spiral
and curve groups.
3 Right-click the Line collection. Click New.
4 In the New Design Check dialog box, for Name, enter L>=310m @ 50km/h.
BEST PRACTICE Because design check tooltips do not display specific values,
a design check name should be specific and unique. Use the mathematical
formula or other specific information to simplify the process of correcting a
design check violation.
5 For Description, enter Tangent length must be >= 310m if design speed
is >= 50km/h.
6 Click Insert Function. Click IF.
The IF function is displayed in the Design Check field.
7 Click Insert Property. Select Design Speed.
8 In the Design Check field, use the keypad to enter >=50, (including the
comma) after the {Design Speed} property.
