Notice that the offset and elevation values that are displayed on the grid
axes do not change. The shape of the Daylight (Right) subassembly
changes to reflect how it ties in to the existing ground surface.
8 On the View Tools panel, click
9 Click
The view zooms back out to the extents of the assembly.
To continue this tutorial, go to

Exercise 2: Editing Corridor Sections

In this exercise, you will edit the parameters at several corridor sections.
You will edit a section in two ways. First, you will modify a subassembly
parameter at a single station, which will override the subassembly settings for
that station only. Second, you will modify a subassembly parameter, and then
apply the modification to a range of stations.
For more information, see the AutoCAD Civil 3D Help topic Editing Corridor
Sections.
This exercise continues from
Modify subassembly properties for a single station
NOTE This exercise uses Corridor-4a.dwg from the previous exercise.
1 On the Station Selection panel, in the Select A Station list, select 7+75.00.
2 On the View Tools panel, click
3 In the Pick Subassembly dialog box, select Lane (Right). Click OK.
4 On the Corridor Edit Tools panel, toolbar, click
5 In the Corridor Parameters dialog box, in the Assembly - (1) tree, under
Group - (1), expand Lane (Right).
Notice that identical values are displayed in the Design Value and Value
columns. The Design Value column displays the value that was specified
when the subassembly was added to the assembly. The Value column
displays the actual value of the subassembly at the current station. In the
480 | Chapter 13 Corridors Tutorials
Go To Next Station.
Exercise 2: Editing Corridor Sections
Exercise 1: Viewing Corridor Sections
Zoom To Extents.
Zoom To A Subassembly.
Parameter Editor.
(page 480).
(page 477).
