14 Click the diamond-shaped label edit grip to make it active. Click a new
location for the label at the start end of the pipe, which is the end located
next to station 8+00.
The start and end of a pipe is determined using the direction in which
the pipe was drawn.
15 Click the square label edit grip to make it active. Click a new location for
the label text that moves it off the pipe.
16 Press Esc to deselect the label.
Next, you will add a spanning label to a series of two pipes in plan view.
Add labels to a single pipe network part in plan view
1 Pan and zoom until you can clearly see the North-South pipe run along
the XC_STORM alignment.
2 In the Add Labels dialog box, specify the following parameters:
Label Type: Spanning Pipes Plan
Pipe Label Style: 2D Length - Total Span
3 Click Add.
4 Click both pipes along the XC_STORM alignment, then press Enter.
5 When prompted, click a location along the pipe span to place the label.
The span label is placed on the pipe run in the location you specified. To
see which pipes are included in the span, hover the cursor over the label
to highlight the pipes.
Add labels to a multiple pipe network parts in plan view
1 Pan and zoom until you can clearly see the plan view of the pipe network.
2 In the Add Labels dialog box, specify the following parameters:
Label Type: Entire Network Plan
Pipe Label Style: Standard
Structure Label Style: Structure Name
3 Click Add.
4 Click a part in the pipe network. All pipes and structures are labeled using
the styles you selected.
648 | Chapter 17 Pipe Network Tutorials
