43 Right-click Vertical Axis
top point of the vertical axis, then click the reference point created in
the previous step. The entire structure moves upward so that the rim
elevation matches the top work plane.
44 Click Generate Bitmap.
45 Click SE Isometric View.
46 Click OK. A bitmap image is generated. This is the image of the part that
is displayed when viewing the part in the part catalog. It is not used not
when viewing the part in a drawing.
704 | Chapter 18 Part Builder Tutorials
Add Constraints
Coincident. Click the
