Exercise 2: Creating a Primary Road Intersection with
Turn Lanes
In this exercise, you will create an intersection with entry and exit turn lanes
at the primary road. The secondary road crown will blend into the primary
road edge of pavement.
You can use the workflow that is demonstrated in this exercise to create an
intersection with any combination of turn lanes at the curb returns.
For more information, see the AutoCAD Civil 3D Help topic Creating
Intersections.
Specify the intersection location and primary road
1 Open Intersection-Create-2.dwg, which is located in the
folder

Exercise 2: Creating a Primary Road Intersection with Turn Lanes | 503

Exercise 2: Creating a Primary Road Intersection
(page 503).
(page 819).
tutorial drawings
