The pipe or structure you selected is drawn in the profile view.
5 Press Esc to deselect the pipe.
6 Select the profile view grid. Right-click. Click Profile View Properties.
7 In the Profile View Properties dialog box, on the Pipe Networks tab, select
the check box in the Draw column for each part entry in the pipe network
except for Pipe - (10), Pipe - (10)(1), Structure (11), and Structure (12).
8 Click OK.
All the pipe network parts you selected in Profile View Properties are
displayed in the profile view.
To continue this tutorial, go to
Parts (page 646).

Exercise 2: Adding Labels to Pipe Network Parts

In this exercise, you will add labels to the pipe network parts drawn in both
plan and profile views.
NOTE For more detailed tutorials on labels, go to the
(page 739).
For more information, see the AutoCAD Civil 3D Help topic Labeling Pipe
Networks.
This exercise continues from
Profile View
Add labels to pipe network parts in a profile
NOTE This exercise uses Pipe Networks-3.dwg with the modifications you made
in the previous exercise.
1 Zoom to the pipe network parts drawn in the profile view.
2 Click Annotate tab
Network
3 In the Add Labels dialog box, specify the following parameters:
Label Type: Single Part Profile
Pipe Label Style: Standard
646 | Chapter 17 Pipe Network Tutorials
Exercise 2: Adding Labels to Pipe Network
Exercise 1: Drawing Pipe Network Parts in a
(page 645).
Labels & Tables panel
Add Pipe Network Labels
Labels and Tables Tutorials
Add Labels menu
.
Pipe
