In the Properties window, under Misc, notice the Standard Scale property.
This value should match the drawing scale of the source drawing.
3 Close the Properties window.
4 On the AutoCAD status bar, right-click
Model Tabs.
At the bottom of the drawing, Model, Layout, and Sheet tabs are displayed.
5 Click the Model tab.
Modify a section view
1 Zoom in to the first section view, which is in the lower left-hand corner
of the leftmost section sheet.
2 On the left-hand side of the section view, select the offset and elevation
label.
3 Click the
grip. Drag the grip up and to the right. Click the place the
label.
4 Repeat Steps 2 and 3 to move the offset and elevation label on the
right-hand side of the section view.
5 At the bottom of the drawing, click the Section Sheet - (1) tab.
6 Zoom in to the first section view, which is in the lower left-hand corner
of the layout.
The label changes have been applied to the section view. The model is
dynamically linked to the section view sheets.
Click Display Layout and
Exercise 2: Creating Section Sheets | 817
